Genuine Amerex service part·Part no. 16483
Amerex 16483 Hardware Bag Assembly, Class D 300 Wheeled Unit
Amerex 16483 is the bolt, washer and wing nut set (Amerex part 16483, item 18) that clamps the expellant cylinder retaining strap to the carriage on cylinder-operated wheeled extinguishers. Full overview ↓
- Part no.
- 16483
- Pack
- Pack of 1
- Parts Book
- Page 19
- UPS-calculated at checkout. Free shipping on orders over $100.
- Returns per our refund policy.
Genuine Amerex part from an authorized Amerex distributor. Not a generic substitute.
Ordering parts for a service route?
Quotes for part lists, PO and tax-exempt orders, and parts not yet listed.
Which models does the Amerex 16483 fit?
Per the Amerex Parts Book · page 19| Fits | Extinguisher | UL rating | Capacity | Price | Link |
|---|---|---|---|---|---|
| Model 491 |  11677 Amerex 491 300 lb Wheeled ABC Fire ExtinguisherParts Book p.19 (PDF p.21) |
40A:320B:C | 300 lb (136.07 kg) | $9,515.00 | View |
| Model 493 |  15505 Amerex 493 300 lb Wheeled Purple K Fire ExtinguisherParts Book p.19 (PDF p.21) |
320B:C | 300 lb (136.07 kg) | $9,413.00 | View |
| Model 680R |  10897 Amerex 680R 150 lb Wheeled Sodium Chloride Fire ExtinguisherParts Book p.23 (PDF p.25) |
150 lb | $12,075.00 | View | |
| Model 681R |  10898 Amerex 681R 250 lb Wheeled Copper Powder Fire ExtinguisherParts Book p.23 (PDF p.25) |
250 lb | $16,921.00 | View |
Parts list for 125/150 lb. dry chemical wheeled models, 110 cu. ft. nitrogen cylinder
Fitment per the Amerex Parts Book. Check the part number against your unit’s nameplate before ordering.
What is the Amerex 16483?
Amerex 16483 is the bolt, washer and wing nut set (Amerex part 16483, item 18) that clamps the expellant cylinder retaining strap to the carriage on cylinder-operated wheeled extinguishers. The Parts Book lists it for the 110 cu. ft. models (467, 469, 470, 472) at item 18, the 55 cu. ft. models (491, 493) at item 20, and the Argon-charged 680R/681R Class D units at item 18. The owner's recharge procedure has the technician unscrew the wing nuts to remove the expellant cylinder from the extinguisher. The Parts Book notice states Amerex replacement parts must be used to protect the UL listing and keep the warranty in effect.
Amerex 16483 specifications
| Part number | 16483 |
|---|---|
| Description | Bolt, Washer and Wing Nut |
| Parts Book page | Printed p.17 (PDF p.19) |
| Diagram item | 18 |
| Pack quantity | 1 |
| Models | 467, 469, 470, 472, 491, 493, 680R, 681R |
|---|
| Amerex item number | 16483 |
|---|
Part data as published by Amerex. Confirm against the current Parts Book revision before ordering for a unit in service.
Amerex 16483 documents
Official Amerex publications · PDF- Parts Book p. 19 Parts list for 125/150 lb dry chemical, 110 cu. ft. nitrogen cylinder wheeled models 467, 469, 470, 472
- Owner's Service Manual (05605) Wheeled 125/150 lb N2 cylinder operated - models 450/452/467/469/470/472
- Owner's Service Manual (05614) Wheeled 300/350 lb N2 cylinder operated - models 491/492/493
- Owner's Service Manual (05620) Wheeled 150/250 lb Class D - models 680/681
- Tech Tip - Amerex Products Need Amerex Parts Why genuine Amerex parts
- Amerex Warranty Statement
Current Amerex publications, hosted on ShopAmerex so links do not break when Amerex reorganizes its site.
Other parts on Parts Book page 19
Parts list for 125/150 lb. dry chemical wheeled models, 110 cu. ft. nitrogen cylinder · All 29 parts| Part no. | Part | Pack | Price | Quantity and add to cart |
|---|---|---|---|---|
| 02234 | Pack of 1 | $113.00 | ||
| 02235 | Pack of 1 | $1,152.00 | ||
| 02272-P001 | Pack of 1 | $5.99 | ||
| 04128 | Pack of 1 | $1,606.00 | ||
| 04444 | Pack of 1 | $69.99 | ||
| 04523 | Pack of 1 | $28.99 | ||
| 06032 | Pack of 1 | $88.99 | ||
| 06993 | Pack of 1 | $176.00 |
Item numbers refer to the exploded view on the Parts Book page. Model-specific items are marked in the Amerex parts list; confirm before ordering.
Amerex 16483 questions
What does the Amerex 16483 hardware fit?
The expellant cylinder retaining strap on the 110 cu. ft. models (467, 469, 470, 472), the 55 cu. ft. models (491, 493) and the Argon-charged 680R/681R Class D units.
Does it fit a “Class D 300” wheeled unit as the title suggests?
Only partly - it is listed on the Class D page, but for the 150 lb and 250 lb models 680R and 681R; the Parts Book has no Class D 300 lb model.
What does it secure?
The retaining straps that hold the nitrogen or Argon cylinder on the carriage, listed at the adjacent items on the same pages.
When is it removed?
The owner's recharge procedure has the technician install the shipping cap, unscrew the wing nuts and remove the expellant cylinder from the extinguisher.
Where is it in the Parts Book?
Item 18 on printed p.17 (PDF p.19), item 20 on p.19 and item 18 on p.23.
Does the 23 cu. ft. family use it?
No - the 450/452 page lists a different bolt, washer and wing nut set, part 11970.
Why use the genuine Amerex part?
The Parts Book notice states the Amerex warranty is voided by generic, off-the-shelf or substitute parts, and that failure to use Amerex replacement parts could cause the extinguisher to malfunction.
